d1071.34 F4U starboard side wing

d1071.34 F4U starboard side wing

To accommodate a folding wing the designers considered retracting the main landing gear rearward but, for the chord of wing that was chosen, it was difficult to make the landing gear struts long enough to provide ground clearance for the large propeller. Their solution was an inverted gull wing, which considerably shortened the required length of the main gear legs. The anhedral of the wing's center-section also permitted the wing and fuselage to meet at the optimum angle for minimizing drag, without using wing root fairings. The bent wing, however, was heavier and more difficult to construct thus offsetting these benefits.
