1092.37a F-16 Falcon tail back behind cockpit

1092.37a F-16 Falcon tail back behind cockpit

The F-16 'Falcon' has a moderate wing loading, reduced by fuselage lift. The vortex lift effect is increased by leading edge extensions, known as strakes. Strakes act as additional short-span, triangular wings running from the wing root (the juncture with the fuselage) to a point further forward on the fuselage. Blended into the fuselage and along the wing root, the strake generates a high-speed vortex that remains attached to the top of the wing as the angle of attack increases, generating additional lift and allowing greater angles of attack without stalling. Strakes allow a smaller, lower-aspect-ratio wing, which increases roll rates and directional stability while decreasing weight. Deeper wing-roots also increase structural strength and internal fuel volume.
